Tata Ace Gold CNG Plus

Tata Ace Gold CNG Plus Key Features

Tata Ace Gold CNG Plus Variants

The Tata Ace Gold CNG Plus is offered in 1 variants - the base model of Tata Ace Gold CNG Plus is 659780 and the top variant is 659780 which come with 694 cc, D+1, 19.4 kW @4000 (+/-100) rpm, 51 Nm, 2 cylinders, 105 L, 1630 Kg and 640 Kg.

Tata Ace Gold CNG Plus Detailed Overview

• Engine and Performance

  Powering the Tata Ace Gold CNG Plus is a two-cylinder, 694cc petrol engine, which is currently one of the smallest and most reliable petrol engines among commercial vehicles. Paired with a 4-speed manual gearbox, this petrol engine produces a maximum power output of 25 PS, while its peak torque output is rated at 51 Nm.

  Summary

  The two-cylinder, 694cc petrol engine of the Tata Ace CNG Plus is coupled to a 5-speed manual gearbox and produces 25 PS of power output and 51 Nm of torque output.

• Suspension and Brakes

  The rugged and simple mechanical setup of the Tata Ace CNG Plus under its skin consists of a hardcore suspension setup, which is a combination of parabolic leaf springs at the front and semi-elliptical leaf springs at the rear. The Tata Ace CNG Plus comes with 145/80 R12 tubeless tyres, which although small in size, are perfect enough to suit the compact dimensions of the Ace CNG Plus. In terms of braking, the Tata Ace CNG Plus is equipped with disc brakes at the front and drum brakes at the rear.

  Summary

  Equipped with 12-inch tyres, the Tata Ace Ace CNG Plus comes with parabolic leaf springs at the front and semi-elliptical leaf springs at the rear.

• Payload

  The Tata Ace CNG Plus measures 4,075mm long, 1,500mm wide and 1,840mm tall. With these dimensions in place, the Tata Ace CNG Plus is one of the smallest commercial vehicles available in the market right now. However, despite its overall compact dimensions and compact cargo box, which measures 2,520mm long, 1,490mm wide and 300mm tall, the Tata Ace CNG Plus has an impressive load-carrying capacity of 600 kg. The overall gross weight of the Tata Ace Ace CNG Plus is 1,630 kg.

  Summary

  Measuring 4,075 long, 1,500mm wide and 1,840mm tall, the Tata Ace CNG Plus has an impressive load-carrying capacity of 600 kg.

• Exterior

  The Tata Ace Ace CNG Plus is essentially the first-generation version of the Tata Ace, which was launched in 2005. It retains the classic simple design of the first-ever Ace, with a windscreen curved from the top, rounded all-halogen headlamps and a split design for the front grille. The headlamps here are accompanied by tiny rounded amber turn indicators above them. The Tata Ace CNG Plus gets a blacked-out front bumper, a sharp crease running through its doors and an S-themed window waistline. The Tata Ace CNG Plus includes three CNG cylinders of 6 kg each which makes a total of 18 kg CNG.

  Summary

  The Tata Ace CNG Plus retains the original design of the first-ever Ace, with it getting rounded lights and a split horizontal grille.

• Interior

  The bare-basic cabin of the Tata Ace CNG Plus has an all-grey theme, which makes it look basic and feels built to a cost. This basic feel of this cabin is further evident in the lack of features, with the Tata Ace CNG Plus getting only a two-spoke steering wheel and an all-digital instrument console placed above the middle of the dashboard and a gear position advisor.

  Summary

  The bare-bones, all-grey cabin of the Tata Ace CNG Plus gets a two-spoke steering wheel and a centrally-placed digital instrument console.

• Features

  Despite it being an entry-level compact commercial vehicle, the Tata Ace CNG Plus is decently armed with features like a lockable glovebox on the co-passenger side and a part-digital theme for the instrument console. The other features offered in the Tata Ace CNG Plus include a bottle and document holder, a USB charger and a 1-DIN audio system.

  Summary

  The Tata Ace CNG Plus gets basic features like a 1-DIN audio system, a part-digital instrument console and a lockable glovebox.
