Tata T.7 Ultra

Tata T.7 Ultra Key Features

Tata T.7 Ultra Variants

The Tata T.7 Ultra is offered in 9 variants - the base model of Tata T.7 Ultra is 1563640 and the top variant is 1847500 which come with Diesel, 98 HP, 2956 cc and 60 L.

Tata T.7 Ultra Detailed Overview

• Engine and Performance

  The only engine option with which all the variants of Tata T7 Ultra are available is a 3.0-liter 4SPCR diesel engine, which is available with a 5-speed G400 manual gearbox as standard. This engine is capable of producing a maximum power output of 100 PS, while the peak torque output of this engine is rated at 300 Nm. The clutch here is a single plate dry friction type, which measures 280mm in diameter.

  Summary

  The 3.0-litre diesel engine of the Tata T7 Ultra produces 100 PS of power and 300 Nm of torque, and is mated to a 5-speed manual gearbox.

• Suspension and Brakes

  The suspension combination of the Tata T7 Ultra comprises parabolic leaf springs at the front and semi-elliptical leaf springs at the rear, both of which come equipped with hydraulic double-acting shock absorbers. All the variants of the T7 Ultra are equipped with 235/75 R17.5 tyres and come with air brakes with an auto slack adjuster.

  Summary

  Riding on 235/75 R17.5 tyres, the Tata T7 Ultra features parabolic leaf springs at the front and semi-elliptical leaf springs at the rear.

• Payload

  The Tata T7 Ultra is available in three variants – CBC, FSD and HDLB. Here, while the FSD and HDLB variants measure 5770mm long and 5720mm wide, the CBC variant is 5720mm long and 1905mm wide. Also, while the CBC and FSD variants are 2450mm wide, the HDLB variant is 2640mm wide. The minimum ground clearance and turning radius of all the three variants of Tata T7 Ultra are 192mm and 6.5m respectively. The deck, which measures 12 ft in length, is capable of hauling 3692 kg to 4935 kg.

  Summary

  With payload capacity varying between 3692 kg to 4935 kg, the Tata T7 Ultra has a 192mm ground clearance.

• Exterior

  The Tata T7 Ultra is one of the most unique-looking light-duty commercial trucks, with its youthful looks of it indicating how Tata has progressed in commercial vehicle designs in all these years. The attention-grabbing element of the front profile of the Tata T7 Ultra is the large inverted trapezoidal black applique positioned just below the front windscreen. The rest of the design of the front apron looks simple with large and vertically aligned trapezoidal headlamps on the lower corners, which come assisted with small air vents placed just beside them. The front bumper looks fairly large for the truck and gets white-coloured surrounds for the fog lamp provisions.

  Summary

  The trapezoidal influence in the design of the Tata T7 Ultra is evident in the looks of the black applique below the front windscreen and headlamps.

• Interior

  The cabin of the Tata T7 Ultra has a grey finish for the entire layout, but it looks eye-catching thanks to the busy layout of the dashboard. There is a sense of simplicity in the driver’s cockpit comprising of a four-spoke steering wheel and a well-informative instrument console. The centre console has a busy design, which comprises vertical layouts for the 1-DIN audio system, open storage space and AC dial, with AC vents and switch panels on either side. The transmission lever is mounted on the dashboard just below the centre console on a rounded pad. There is also a small glovebox on the lower dashboard on the co-passenger side.

  Summary

  The grey-coloured cabin of the Tata T7 Ultra has a busy design, and gets complimented by small storage spaces.

• Features

  The cabin of the Tata T7 Ultra is decently armed with usable features like MID in the instrument console, power steering, manual AC and a 1-DIN audio system.

  Summary

  The Tata T7 Ultra is equipped with all the essential features, comprising a music system and manual AC as standard.
