Tata LPT 510 Truck

Tata LPT 510 Truck Truck Specs & Features

Tata LPT 510 Truck Price List Variants

The Tata LPT 510 Truck is offered in 1 variants - the base model of Tata LPT 510 Truck is 1472000 and the top variant is 1472000 which come with 2956 cc, 300 Nm, 4 cylinders and 60 L.

Tata LPT 510 Truck Detailed Overview

• Overview

  The Tata LPT 510 stands tall as a robust and reliable commercial vehicle, tailored to meet the demands of efficient cargo transportation. With a perfect fusion of power, performance, and features, this vehicle is a testament to Tata's commitment to the commercial sector.

• Performance Excellence

  The Tata LPT 510 is equipped with a 2956 cc engine, delivering a powerful performance of 100 hp and a peak torque of 300 Nm. With a mileage of 10 kmpl and a gradeability of 37%, this vehicle ensures optimal efficiency for commercial operations.

  Summary

  2956 cc engine, 100 hp power, 300 Nm torque, and 10 kmpl mileage.

• Smart Design & Dimensions

  The vehicle's design is well-thought-out, with a chassis and cabin configuration that optimizes payload capacity. The wheelbase of 2775 mm and overall dimensions of 5215 mm length, 2255 mm width, and 2326 mm height contribute to its agility on varied terrains.

  Summary

  2775 mm wheelbase, 5215 mm length, and optimized payload capacity.

• Transmission & Loading Capacity

  The manual transmission with 5 forward and 1 reverse gears, along with a robust clutch system, ensures seamless operation. The payload capacity reaches 2177 Kgs, with a Gross Vehicle Weight (GVW) of 5490 kg, making it ideal for diverse cargo needs.

  Summary

  5+1 gearbox, 2177 Kgs payload, and 5490 kg GVW.

• Features for Comfort & Control

  The Tata LPT 510 comes with power steering, enhancing driver control and maneuverability. The 4-way adjustable driver seat, tilt and telescopic steering, and thoughtful features like adjustable seat belts ensure a comfortable and secure driving experience.

  Summary

  Power steering, adjustable driver seat, and ergonomic design for driver comfort.

• Safety & Reliability

  The vehicle incorporates hydraulic brakes with auto slack adjuster and booster, ensuring effective braking. The robust chassis, semi-elliptical leaf springs, and parabolic auxiliary suspension contribute to a smooth and safe ride. The day cabin is equipped with essential safety features, including parking brakes.

  Summary

  Hydraulic brakes, semi-elliptical leaf springs, and safety-focused design.

• Engine and Performance

  The Tata LPT 510 is powered by a 4-cylinder, 2956cc, 4SPCR diesel engine that produces 100 horsepower and 300 Nm of torque. The engine is mated to a 5-speed manual transmission and has a top speed of 90 km/h. The vehicle has a fuel tank capacity of 120 liters and a fuel efficiency of 10-12 km/l.

  Summary

  The 510 LPT's engine provides a good balance of power and efficiency for its intended use.
