टाटा 510 एस एफ सी टीटी

टाटा 510 एस एफ सी टीटी प्रमुख फीचर्स

टाटा 510 एस एफ सी टीटी वैरिएंट्स

टाटा 510 एस एफ सी टीटी को 3 वेरिएंट में पेश किया गया है - टाटा 510 एस एफ सी टीटी का बेस मॉडल 1336000 है और टॉप वेरिएंट 1384000 है। जो साथ आता है 98 HP, 4 cylinders and 60 L.

टाटा 510 एस एफ सी टीटी Detailed Overview

• अवलोकन

  The smallest dual tire truck with the highest profit per kilometer is the Tata 510 SFC TT. It's a brand-new variation of the esteemed SFC 407 TT/31. This truck falls below the 5.5-tonnage limit for year-round commercial use. It is a light-duty vehicle with the best gradability in its class and a greater payload space. Tata SFC 510 Truck's SFC stands for Semi Forward Cabin Chassis. The engine is located partially under and partially in front of the driver's cabin in an SFC-styled car. Only Tata Motors Limited produces commercial vehicles in India with cabins in the SFC design. To ensure utmost safety, it includes a special NOSE front.

• इंजन और गियरबॉक्स

  The 510 SFC TT is equipped with a reliable 2956cc 4SPCR, BS6 engine. To handle all cargo-related tasks, a maximum of 98 horsepower and 300 Nm of torque are required. Tata's 5-speed manual G400 gearbox is tailored to work with the engine for smooth driving.

  Summary

  The Tata 510 SFC TT features a Semi Forward Cabin Chassis (SFC) design for safety and practicality.

• सस्पेंशन

  The front suspension consists of two hydraulic double-acting shock absorbers and a parabolic spring with a rubber bush. A semi-elliptical leaf spring and two hydraulic double-acting shock absorbers make up the rear suspension.

  Summary

  Powered by a 2956cc BS6 engine, it offers 98 horsepower and 300 Nm of torque, paired with a 5-speed manual G400 gearbox.

• आयाम

  The gross weight of this twin-tire LCV, which has a wheelbase of 3305 mm, is 5300 kg. The turning diameter is 13.1 meters, and the ground clearance is 189 millimeters.

  Summary

  The truck's suspension includes hydraulic double-acting shock absorbers and parabolic springs at the front and semi-elliptical leaf springs with shock absorbers at the rear.

• ईंधन टैंक और टायर

  As the name implies, this LCV has twin tires at the back, each measuring 7.00 R 16LT, with 12PR- tires at the front two and the back four. One spare tire is provided, and a 60L fuel tank is included.

  Summary

  With a 3305 mm wheelbase, 5300 kg gross weight, and 189 mm ground clearance, it offers stability and maneuverability.

• विशेषताएँ

  The ladder-type frame of the Tata SFC 510 model features eight cross members that are riveted or fastened. The long member's measurements are 180 MM long, 55 MM wide, and 5 MM high. Even on bad roads, thanks to the 189 MM minimum ground clearance, the ride is safe and comfortable. With a 3305 MM wheelbase, this Tata 510 SFC TT Truck has an ergonomic design.

  Summary

  Equipped with twin tires at the back, 7.00 R 16LT tires, 12PR tires at the front and back, and a 60L fuel tank, it's designed for efficiency and reliability.
